584T
All-in-One Computer with Integrated Swappable Batteries for Point-of-Care Applications
Powered by a powerful Intel® Core™ Ultra processor, the 584TM All-in-One Medical-Cart Computer features a 24" easy-to-read display to provide at-a-glance examination to ensure efficient operation. With the optional hot-swappable batteries, patient data can be managed fluidly without operations being interrupted due to the act of replacing batteries, while the VESA standard mounting design makes installation an effortless task. The built-in Wi-Fi and other optional data-capture modules further improve the point-of-care process. With these extensive features, the 584TM is ideal for hospitals and clinics in any point-of-care scenarios.
Product ConfiguratorFeatures
- Integrated hot-swappable batteries (optional, up to 3 batteries)
- 24" high-resolution touchscreen
- Intel® Core™ Ultra processor
- Microsoft® Windows® 10/11 IoT Enterprise or Ubuntu OS
- Fanless, space-saving all-in-one design with antimicrobial enclosure
- VESA compatibility to maximize installation flexibility
- Built-in LED reading light
- HDMI video-out, support up to 4K UHD resolution
- ANSI/AAMI ES60601-1 certified
- IP65 sealed front bezel and IPX1 back cover enclosure
Major Options
- Power supply outputs
- 5M Front Camera or IR Camera
- NFC/RFID reader
- Smart card/CAC reader
- DC-Out (12V x 1, 19V x 1, 24V x 1)
Specifications
System
-
CPU
Intel® Core™ Ultra 5 processor 125U, 1.3 GHz(up to 4.3 GHz)
Intel® Core™ Ultra 5 processor 135U, 1.6 GHz(up to 4.4 GHz)
Intel® Core™ Ultra 7 processor 155U, 1.2 GHz (up to 4.8 GHz)
Intel® Core™ Ultra 7 processor 165U, 1.7 GHz (up to 4.9 GHz) -
RAM
8GB to 64GB
-
Storage
256GB to 4TB Flash
-
Operating System
Microsoft® Windows® 10/11 IoT Enterprise or Ubuntu
-
Display
23.8" Touchscreen
-
Display Resolution
1920 x 1080
-
Trusted Platform Module
TPM 2.0
-
Microphone
Built-In Microphones
-
Speaker
Build-In Speaker
-
Reading Light
1 x LED Reading Light
-
Network Interface
Wi-Fi 802.11ax, 2.4/5/6 GHz Three Band
-
BT
BT 5.3
I/O INTERFACE
-
USB Port
3 x USB 3.2 Gen 2 (Type-A), 2 x USB 2.0 (Type-A), 1 x USB 3.2 Gen 2 (Type-C)
-
COM Port
2
-
HDMI Port
1
-
Headphone Jack
1 (3.5 mm)
-
Ethernet Port
1
-
DC-In Jack
1
-
DC-Out (Optional)
12V x 1, 19V x 1, 24V x 1
-
Switches & Buttons
1 x Power Button, 4 x Functional Buttons, 1 x Reading Light On/Off Button
MECHANICAL AND ENVIRONMENTAL
-
Fan/Fanless
Fanless
-
AC/DC Adapter
Input: 100 – 240V AC; Output: 19V DC, 6.31A
-
Battery Pack
(Optional) 3 x Li-Ion Battery (8250mAh, 90Wh)
-
Enclosure
ABS + PC Plastic with Antimicrobial Coating
-
Dimensions (H x W x D)
14.6 x 22.2 x 1.62 in/370.9 x 564.3 x 41.2 mm
-
Weight
16.4 (w/o battery), 19.58 (w/batteries) lbs
-
VESA Mount
100 × 100 mm
-
Water Resistance
IP65 Sealed Front Bezel and IPX1 Back Cover
-
Regulatory and Safety Certifications
ANSI/AAMI ES60601-1, IEC60601-1, IEC60601-1-2, FCC Part 18, FCC Part 15 Class B, GB 17625.1, GB 4943.1, GB/T 9254, CE-EMC, CE-RED, RCM, CCC
-
Temperature
Operation: 0°C ~ 40°C (32°F ~ 104°F); Storage: -20°C ~ 60°C (-4°F ~ 140°F)
-
Humidity
0% ~ 90% Non-Condensing
MAJOR OPTIONS SPECS
-
CAMERA
5M Front Camera or IR Camera
-
NFC/RFID READER
Dual Frequency (Reads 125 KHz & 13.56 MHz Credentials)
-
Smart Card/CAC Reader
Half-Slot (Reads ISO 7816 T=0, T=1 & 1.8/3/5V Smart Card)
DC-Out
12V x 1 / 19V x 1/ 24V x 1
Accessories
Medical Grade AC Adapter with Power Cord
Facilitates system operation and/or battery recharge.
Hot-swappable Battery
DR202; 90W, 8250mAh battery.
6-Bay Gang Charger
Available for charging up to six DR202 batteries.
Desktop Stand for Medical-Cart Computers
VESA-compliant mounting with metal construction. MD-white color.
3-Slot Battery Holster
Supplies powers to the system and peripherals (e.g., Zebra mobile printer and Welch Allyn vital sign monitor).
Battery Holster
Supplies powers to the peripherals (e.g., Zebra mobile printer and Welch Allyn vital sign monitor).
