316T/MD RUGGED MEDICAL TABLET

Slim, Antimicrobial, ANSI/AAMI ES60601-1 Certified Tablet for Efficient Operations

The 316T/MD Rugged Medical Tablet features the integration of a brilliant 15.6" capacitive touch screen and a high performance, energy-efficient Intel® processor within a slim, durable package. With built-in front and back cameras ,Wi-Fi as well as optional data capture modules, this medical tablet offers health professionals an effective tool to monitor, record and retrieve patient information. With its large, vivid display, the 316T/MD Rugged Medical Tablet shows a wide work area and detailed application interface to enhance user experience and workflow.

Product Configurator

Features

  • 15.6" Full-HD capacitive touch screen, digital pen support
  • Intel® Core™ i processor
  • Microsoft® Windows® 10 IoT Enterprise or Ubuntu operating system
  • NIST compliant BIOS available
  • ANSI/AAMI ES60601-1 certified with antimicrobial enclosure
  • Hot swappable battery pack
  • Built-in front and back cameras

Major Options

  • 4K resolution screen
  • Smart card/CAC reader
  • NFC/RFID reader

Specifications

SYSTEM
  • CPU

    Intel® Core™ i5-1135G7, 4-Core, up to 4.2 GHz
    Intel® Core™ i7-1165G7, 4-Core, up to 4.7 GHz

  • RAM

    8GB to 16GB

  • Storage

    256GB to 1TB Flash

  • Operating System

    Microsoft® Windows® 10 IoT Enterprise or Ubuntu

  • NIST Compliance

    NIST compliant BIOS available

  • Display

    15.6” capacitive touch screen

  • Display Resolution

    1920 x 1080, or 3840 x 2160 (optional)

  • WLAN

    Wi-Fi 802.11ax, 2.4GHz/ 5GHz dual band

  • Control Switch and Buttons

    1 power button, 3 programmable buttons

  • Microphone

    Built-in microphone

  • Speaker

    Built-in speaker

  • Camera

    Full-HD front camera and 8 megapixel back camera

I/O PORTS
  • USB Port

    USB 3.0 x 4

  • Headphone-out

    1

  • Ethernet Port

    1

  • DC-in

    1

MECHANICAL AND ENVIRONMENTAL
  • AC/DC Adapter

    Input: 100-240V AC; Output: 18.5V DC, 3.89A

  • Battery Pack

    Hot swappable battery, 11.4V, 5400mAh

  • Enclosure

    ABS + PC plastics and magnesium-aluminum alloy; antimicrobial enclosure

  • Dimensions (H x W x D)

    10.2 x 15.2 x 1.04 in/ 259.6 x 385.2 x 26.4 mm

  • Weight

    4.63 lbs/ 2.1 kg

  • Regulatory

    FCC/IC, CE/CB, RCM, CCC, ANSI/AAMI ES60601-1

  • Temperature

    Operation: -10°C to 60°C (14°F to 140°F)
    Storage: -55°C to 70°C (-67°F to 158°F)

  • Humidity

    0% – 90% non-condensing

MAJOR OPTIONS SPECS
  • NFC/RFID READER

    Dual frequency, reads both 125KHz and 13.56MHz credentials

  • SMART CARD/CAC READER

    Full-slot, reads ISO 7816 T=0, T=1; 1.8/3/5V smart card

Accessories

    6-Bay External Battery Charger
    Battery Gang Charger

    Simultaneously charge 6 external batteries.

    AC/DC Power Adapter with Power Cord
    AC/DC Power Adapter with Power Cord

    Facilitates battery recharge or Tablet operation through direct connection to the Tablet or via the Power Jack in the Charging Cradle. (Choice of North America, UK or EU power cord).

    Tablet Mount Cradle
    Tablet Mount Cradle

    Offers Tablet storage and security with power supply and I/O ports.

    External Battery Pack
    Battery Pack

    Hot swappable, 60W.

    Digital Pen
    Digital Pen

    Dimension: 9.7mm x 140.7mm; Weight: <25g; Battery: 1 AAAA.

    Battery Holster
    3-Slot Battery Holster

    Supplies powers to the system and peripherals (e.g., Zebra mobile printer and Welch Allyn vital sign monitor).
