DT302PA Rugged Tablet

Slim, Rugged, Multi-functional Wireless Computing

The DT302PA Rugged Tablet features the integration of a sunlight readable 10.1” capacitive touchscreen and a highperformance, energy-efficient Intel_® Core™ Ultra processor within a slim, lightweight, durable casing. With a built-in Wi-Fi module as well as options for front/ back cameras, barcode scanner, smart card reader, RFID and GNSS data capture modules, these robust tablets offer seamless information capture and transmission for improved workflow. IP65 rated,MIL-STD-810H and MIL-STD-461G certified with a wide temperature range, the DT302PA Rugged Tablet provides reliable operation in harsh, mission-critical environments.

Product Configurator

Features

10.1" LED-backlit, sunlight-readable (1000 nits) touchscreen digital pen support
Intel_® Core™ Ultra 5/7 processor
Microsoft_® Windows_® 11 IoT Enterprise operating system
NIST compliant BIOS available
Hot-swappable battery for 24/7 operation
Built-in microphone and speaker
Detachable keyboard option for 2-in-1 applications
IP65 rated, MIL-STD-810H and MIL-STD-461G certified
Quick Access SSD
Energy Star 8.0 certified

Major Options

5 MP Front Camera and 13 MP Back Camera
2D Barcode Scanner (Reads 1D and 2D)
GPS Module
4G LTE

*2D Scanner and 4G Module cannot be built onto same device.

Specifications

System

CPU

Intel_® Core™ Ultra 5 Processor 225U, 12 core (up to 4.80 GHz)
Intel_® Core™ Ultra 7 Processor 255U, 12 core (up to 5.20 GHz)
RAM

16G to 32G LPDDR5
Storage

256GB to 4TB
*Support quick access SSD function to easily replace the SSD without opening the back cover
Operating System

Microsoft_® Windows_® 11 IoT Enterprise
NIST Compliance

NIST Compliant BIOS Available
Display

10.1" LED-Backlit, Sunlight-Readable (1000 nits) Touchscreen LCD
Display Resolution

1920 x 1200
Microphone

Built-In Microphone
Speaker

Built-In 2W Speaker

Network Interface

WLAN

Wi-Fi 802.11ax, 2.4/5/6 GHz Three Band
BT

5.3

I/O Ports

USB Port

1 x USB3.2 (Type-A), 1 x USB3.2 latest USB/charging
Headset Jack

1 (3.5 mm)
Ethernet Port

1 x Ethernet 10/100/1000MB Base-T LAN
DC-In Jack

1
24-pin Fischer Minimax Connector (Optional)

1 x USB2.0, COM port, RJ45, Power 5A (in), and Power 2A (out)

MECHANICAL AND ENVIRONMENTAL

AC/DC Adapter

Input: 100 to 240V AC; Output: 19V DC, 3.42A (65W)
Battery Pack

Hot-Swappable Battery (11.4V, 3800mAh)
(Optional) 60W Hot-Swappable Battery (11.4V, 5400mAh)
(Optional) 90W Hot-Swappable Battery, (11.4V, 8000mAh)
Enclosure

ABS + PC plastics and magnesium-aluminum alloy with anti-microbial coating
Dimensions (H x W x D)

7.7 x 10.71 x 0.79 in/195.6 x 272 x 20 mm
Weight

3 lbs/1.32 kg
Durability

IP65, MIL-STD-810H and MIL-STD-461G Certified
Regulatory

CE, FCC Class B, IC, CB, RCM, IEC 60601-1, IEC62680, EPEAT, Energy star 8.0
Temperature

Operation: -10°C to 60°C (14°F to 140°F);
Storage: -50°C to 70°C (-58°F to 158°F)
Humidity

0% to 90% Non-Condensing

MAJOR OPTIONS SPECS

Barcode Scanner

2D Barcode Scanner (Reads 1D and 2D)
Camera

5 MP Front Camera and 13 MP Back Camera
GNSS

GPS
Mobile Broadband

4G LTE

Accessories

Detachable Slim Keyboard

Slim and lightweight with magnetic hinge to effortlessly attach/detach to the DT302RP rugged tablet.

Battery Gang Charger

Simultaneously charge 6 external batteries.

Digital Pen

Dimensions: 9.7mm x 140.7mm; Weight: <25g; Battery: 1 AAAA.

Desktop Charging Cradle

With I/O ports supporting power, USB, COM, and Ethernet.

Tablet Mount Cradle

Offers Tablet storage and security with power supply and I/O ports.

VESA Mounting Bracket

Offers Tablet storage and security.

Battery Charger Kit with AC Adapter and Power cord

Recharges battery pack "offline" without affecting tablet use.

Screen Protector

User-replaceable film screen protector to protect the display from scratches and repeated use. Comes with microfiber cleaning cloth and dust-absorber to make the applying process an easy task.
