DT311YR RUGGED 2-IN-1 TABLET

Slim, Rugged, Multi-functional Wireless Computing

Energy Star mark

The DT311YR Rugged Tablet features the integration of high-brightness 11.6" touchscreen and a highperformance, energy-efficient Intel®Core™ processor within a slim, lightweight, durable package. With built-in smart card/CAC reader and Wi-Fi as well as optional data capture modules, this robust tablet offers seamless information capture and transmission for improved workflow. Rated IP65, MIL-STD-810H/461G and HERO certified with a wide temperature range, the DT311YR Rugged Tablet provides reliable operation in harsh, mission-critical environments.

Product Configurator

Features

  • 11.6" Full-HD capacitive touch screen, 1000 nits, digital pen support
  • Intel® Core™ i5/i7 processor
  • Microsoft® Windows® 10/11 IoT Enterprise operating system
  • NIST compliant BIOS available
  • High capacity, hot-swappable battery pack
  • Built-in smart card/CAC reader
  • Anti-microbial coating
  • IP65 rated, MIL-STD-810H and MIL-STD-461G certified
  • HERO (Hazard of Electromagnetic Radiation to Ordnance) certified
  • Slim keyboard option for 2-in-1 applications
  • Quick Access SSD
  • Energy Star 8.0 certified

Major Options

  • LONG RANGE BT Class 1 (1000 ft)
  • Front and Back Cameras
  • 2D Barcode Scanner (Reads 1D & 2D)
  • UHF RFID Reader
  • GPS Module
  • 4G LTE/AWS

Specifications

System
  • CPU

    Intel® Core™ i7-1355U, 10-Core, up to 5.0 GHz
    Intel® Core™ i5-1335U, 10-Core, up to 4.6 GHz

  • RAM

    8GB to 32GB

  • Storage

    256GB to 2TB Flash
    *Support quick access SSD function to easily replace the SSD without opening the back cover

  • Operating System

    Microsoft® Windows® 10/11 IoT Enterprise

  • NIST Compliance

    NIST Compliant BIOS Available

  • Display

    11.6” LED-Backlit, High-Brightness (1000 nits) Touchscreen

  • Display Resolution

    1920 x 1080

  • WLAN

    Wi-Fi 802.11ax, 2.4/5 GHz Dual Band

  • Microphone

    Built-In Microphone

  • Speaker

    Built-In Speaker

I/O INTERFACES
  • USB Port

    1 x USB 3.0, 1 x USB Type-C

  • Headset Jack

    1 (3.5 mm)

  • Ethernet Port

    1 x Ethernet 10/100/1000MB Base-T LAN

  • DC-In

    1

  • Smart Card/CAC Reader

    Full Slot (reads ISO 7816 T=0, T=1); 1.8/3/5V Smart Card

  • Switches & Buttons

    1 x Power Button, 2 x Brightness Buttons, 5 x Programmable Buttons

MECHANICAL AND ENVIRONMENTAL
  • AC/DC Adapter

    Input: 100 – 240V AC; Output: 20V DC, 3.25A

  • Battery Pack

    Hot-Swappable Battery (11.4V, 5400mAh)
    Hot-Swappable Battery (11.4V, 8000mAh)(Optional)

  • Enclosure

    ABS + PC Plastic and Magnesium-Aluminum Alloy

  • Dimensions (H x W x D)

    8.3 x 12.4 x 0.86 in/212 x 316 x 21.9 mm

  • Weight

    3.5 lbs/1.6 kg

  • Durability

    IP65, MIL-STD-810H and MIL-STD-461G Certified

  • Hazard of Electromagnetic Radiation to Ordnance (HERO) Testing


    Yes

  • Regulatory

    CE, FCC Class B, RoHS, EnergyStar 8.0

  • Temperature

    Operation*: -10°C ~ 60°C (14°F ~ 140°F)
    Optional -30°C ~ 60°C (-22°F ~ 140°F)
    Storage: -50°C ~ 70°C (-58°F ~ 158°F)
    *For battery optimal functionality and performance, the recommended usage temperature range is from 0°C ~ 50°C (32°F ~ 122°F)

  • Humidity

    0% ~ 90% Non-Condensing

MAJOR OPTIONS SPECS
  • BARCODE SCANNER

    2D Barcode Scanner (Reads 1D & 2D)

  • CAMERA

    2MP Front Camera & 8MP Back Camera

  • LONG RANGE BT

    Class 1 BT (1000 ft)

  • UHF RFID READER

    865 – 928MHz, EPCglobal Class 1 Gen 2/ISO 18000-6C; 30 ft (9.14m) Reading Distance

  • GNSS MODULE

    U-blox M9N GNSS Module

  • MOBILE BROADBAND

    4G LTE/AWS

Accessories

    Slim Detachable Keyboard
    Detachable Slim Keyboard

    Slim and lightweight with magnetic hinge to effortlessly attach/detach to the DT311YR rugged tablet.

    Battery Gang Charger
    Battery Gang Charger

    Simultaneously charge 6 external batteries.

    Digital Pen
    Digital Pen

    Dimensions: 9.7mm x 140.7mm; Weight: <25g; Battery: 1 AAAA.

    Desktop Charging Cradle
    Desktop Charging Cradle

    With I/O ports supporting power, USB, HDMI, COM, and Ethernet.

    Tablet Mount Cradle
    Tablet Mount Cradle

    Offers Tablet storage and security with power supply and I/O ports.

    Battery Charger Kit with AC Adapter and Power cord
    Battery Charger Kit with AC Adapter and Power cord

    Recharges battery pack "offline" without affecting tablet use.

    AC/DC Power Adapter with Power Cord
    AC/DC Power Adapter with Power Cord

    Facilitates battery recharge or Tablet operation through direct connection to the Tablet or via the Power Jack in the Charging Cradle. (Choice of North America, UK or EU power cord).

    Keyboard Mounting Kit for Vehicle/Wall Mount Cradle
    Keyboard Mounting Kit for Vehicle/Wall Mount Cradle

    Includes ACC-008-50T and DTR packaging. Designed to be attached with the Wall/Vehicle Mount Cradle. The Keyboard Mounting Kit can be folded up when not in use.

    Carrying Case
    Carrying Case

    Open-to-use design with foldable tabletop stand. Made of 1680 denier nylon fiber with water-repellent coating.

    Carrying Case and Portfolio
    Carrying Case and Portfolio

    Added protection and secure portability to guard Rugged Tablets from scratches, bumps, and drops.

    Digital Pen
    10.1”/11.6”/13.3” Screen Protector

    User-replaceable film screen protector to protect the display from scratches and repeated use. Comes with microfiber cleaning cloth and dust-absorber to make the applying process an easy task.

    Shoulder Strap for Tablets
    Shoulder Strap for Tablets

    Padded for comfort, provides convenient mobile operation, strap is adjustable and can be attached to the Rubber Grips.

    Automobile Power Adapter by LIND
    Automobile Power Adapter by LIND

    Output voltage 65W/ 19V Input: 11-16V DC.

    X-Handstrap
    X-Handstrap

    Designed to securely hold the Tablet. Made of soft plastic, easy to clean. For left- or right-handed users.

    High Capacity Battery Pack
    High Capacity Battery Pack

    Hot swappable, 60W or 90W.
