DT313T-MD MEDICAL TABLET

Slim, Anti-microbial, UL60601-1 Certified Tablet for Efficient Operations

The DT313T-MD Medical Tablet features the integration of a brilliant 13.3" capacitive touch screen and a high performance, energy-efficient Intel® Core™ i series processor within a slim, durable package. With built-in Wi-Fi and Bluetooth as well as options for data capture modules, this robust tablet offers health professionals an effective tool to monitor, record and retrieve patient information. With its large, vivid display, the DT313T-MD Medical Tablet shows a wide work area and detailed application interface to enhance user experience and workflow.

Product Configurator

Features

  • 13.3” full-HD LCD display with capacitive touch, digital pen support
  • Intel® 8th Generation Core™ i series processor
  • Microsoft® Windows® 10 IoT Enterprise operating system
  • NIST compliant BIOS available
  • Built-in front and back cameras
  • UL60601-1 certified with anti-microbial enclosure
  • High capacity, hot-swappable battery pack
  • Built-in foldable tabletop stand and optional handle

Major Options

  • 2D barcode scanner; reads 1D also

Specifications

SYSTEM
  • CPU

    Intel® Core™ i5-8250U, Quad-Core, 1.6GHz (up to 3.4GHz)

  • RAM

    8GB to 16GB

  • Storage

    256GB to 512GB Flash

  • Operating System

    Microsoft® Windows® 10 IoT Enterprise

  • NIST Compliance

    NIST compliant BIOS available

  • Display

    13.3” LED-backlight screen with capacitive touch

  • Display Resolution

    1920 x 1080

  • Network Interface

    Wi-Fi 802.11ac, 2.4GHz/ 5GHz dual band; Bluetooth 4.2 LE

  • Control Switch and Buttons

    1 power button, 1 trigger button, 3 programmable buttons

  • Speaker

    Built-in speaker

  • Cameras

    Full-HD front camera and 8 megapixel back camera

I/O PORTS
  • USB 3.0 Port

    USB 3.0 x 1, USB 2.0 x 2

  • Headphone-out

    1

  • Ethernet Port

    Ethernet 10/ 100/ 1000MB Base-T LAN

  • HDMI-out

    1

  • DC-in

    1

MECHANICAL AND ENVIRONMENTAL
  • AC/DC Adapter

    Input: 100 – 240V AC; Output: 19V DC, 3.42A

  • Battery Pack

    Hot swappable battery, 11.4V, 5400mAh

  • Enclosure

    ABS + PC plastics and magnesium-aluminum alloy; anti-microbial enclosure

  • Dimensions (H x W x D)

    10.6 x 13.2 x 0.8 in/ 270 x 335 x 21 mm

  • Weight

    3.97 lbs/ 1.8 kg

  • Regulatory

    FCC Class B, UL60601-1, CE, RoHS compliant

  • Temperature

    Operation: 0°C – 40°C; Storage: -55°C – 70°C

  • Humidity

    0% – 90% non-condensing

MAJOR OPTIONS SPECS
  • BARCODE SCANNER
  • 2D scanner, reads 1D also

Accessories

    6-Bay External Battery Charger
    Battery Gang Charger

    Simultaneously charge 6 external batteries.

    AC/DC Power Adapter with Power Cord
    AC/DC Power Adapter with Power Cord

    Facilitates battery recharge or Tablet operation through direct connection to the Tablet or via the Power Jack in the device Cradle. (Choice of North America, UK or EU power cord).

    DisplayPort-Male to DVI-Female Adapter
    DisplayPort-Male to DVI-Female Adapter

    Length: 0.2M / 7.9 Inch; for desktop cradle dual display outputs.

    External Battery Pack
    Battery Pack

    Hot swappable, 60W.

    Digital Pen
    Digital Pen

    Dimension: 9.7mm x 140.7mm; Weight: <25g. Battery: 1 AAAA.

    Tablet Mount Cradle
    Tablet Mount Cradle

    Offers Tablet storage and security with power, HDMI-out, COM, Ethernet pass-through, and USB ports. Power supply is not included.

    Wall/Vehicle Mount Cradle
    Wall/Vehicle Mount Cradle

    This wall/vehicle mount cradle offers Tablet storage and security with power, Ethernet pass-through, and two USB ports. Power supply is not included.

    Keyboard Mounting Kit for Vehicle/Wall Mount Cradle
    Keyboard Mounting Kit for Vehicle/Wall Mount Cradle

    Designed to be attached with the Wall/Vehicle Mount Cradle. The Keyboard Mounting Kit can be folded up when not in use.

    Automobile Power Adapter by LIND
    Automobile Power Adapter by LIND

    Output voltage 65W/ 19V. Input: 11-16V DC.

    Mini-USB Keyboard w/ Hub
    Mini-USB Keyboard w/ Hub

    88-key USB keyboard in compact form factor can be used directly with the device or connected through the Cradle. USA Only.

    USB Mouse
    USB Mouse

    For comfort and control of your computing experience, this two-button mouse has fast, accurate response.

    Shoulder Strap for Tablets
    Shoulder Strap for Tablets

    Padded for comfort, provides convenient mobile operation, strap is adjustable and can be attached to the Rubber Grips.

    DT313 Carrying Handle
    Carrying Handle

    Carrying Handle for DT313T-MD Tablets. Factory installed only.

    X-Handstrap
    X-Handstrap

    Designed to securely hold the Tablet. Made of soft plastic, easy to clean. For left- or right-handed users.
