DT362D Handheld Rugged Tablet

Slim, Rugged, Multi-functional Wireless Computing

The DT362D Handheld Rugged Tablet features the Microsoft® Windows® operating systems enabling flexible integration with many applications. With a powerful Intel® processor, these handheld tablets offer high-performance and energy-efficient operations, while the slim and robust design enhances portability and mobility. With built-in Wi-Fi, BT connectivity, along with optional features such as 2D barcode scanner, 5 MP front camera and 8 MP back camera, NFC/RFID Reader, UHF RFID Reader, and GPS to enhance versatility, the DT362D Handheld Rugged Tablet guarantees reliable operation and expansive functionality for demanding, mission-critical environments.

Product Configurator

Features

  • 6” touchscreen, digital pen support
  • Intel® N200 or Intel® Core™ i3-N300 processor
  • Microsoft® Windows® 11 IoT Enterprise operating system
  • Hot-swappable battery pack
  • IP65-rated for water and dust resistance
  • MIL-STD-810H for shock and vibration protection
  • MIL-STD-461G for EMI and EMC tolerance

Major Options

  • Barcode Scanner or Long Range Barcode Scanner
  • NFC or UHF RFID reader
  • 5 MP Front Camera / 8 MP Back Camera
  • GPS Module

Specifications

System
  • CPU

    DT362DN: Intel® N200, 4-core (up to 3.70 GHz)
    DT362DH: Intel® Core™ i3-N300, 8-core (up to 3.80 GHz)

  • RAM

    16GB

  • Storage

    512GB to 1TB

  • Operating System

    Microsoft® Windows® 11 IoT Enterprise

  • NIST Compliance

    NIST Compliant BIOS Available

  • Display

    6" LED-Backlit (850 nits) touchscreen

  • Display Resolution

    2160 x 1080 (2K)

  • Speaker

    Built-In Speaker

  • Microphone

    Built-In Microphone

Network Interface
  • WLAN

    Wi-Fi 802.11ax, 2.4/5/6 GHz Three Band

  • BT

    5.3

I/O INTERFACES
  • USB Port

    USB Type-C x 1 (data transmitting and charging; data transmitting only available in one insertion direction)

  • Micro SIM Card Slot

    1 x Micro SD Card Slot (DT362DN only)

  • Smart Card/CAC Reader

    Full Slot (Reads ISO 7816 T=0, T=1); 1.8/3/5V Smart Card

  • Control Switch and Buttons

    1 x Power Button, 2 x Programmable Buttons

MECHANICAL AND ENVIRONMENTAL
  • AC/DC Adapter

    Input: 100 ~ 240V AC; Output: 20V DC, 3.25A

  • Battery Pack

    Hot-Swappable Battery (2700mAh)

  • Enclosure

    ABS + PC Plastic

  • Dimensions (H x W x D)

    7.6 x 3.7 x 1.2 in/192 x 95 x 31 mm

  • Weight

    1.1 lbs/485 g

  • Durability

    IP65, MIL-STD-810H and MIL-STD-461G Certified

  • Regulatory

    CE, FCC Class B, RoHS, UL

  • Temperature

    Operation: 0°C ~ 50°C (32°F ~ 122°F ); Storage: -50°C ~ 70°C (-58°F ~ 158°F)

  • Humidity

    0% ~ 90% Non-Condensing

MAJOR OPTIONS SPECS
  • Camera

    5 MP Front USB Camera & 8 MP Back USB Camera

  • Barcode Scanner

    2D Barcode Scanner (Reads 1D & 2D)
    Long Range 2D Barcode Scanner (up to 60ft)

  • NFC/RFID Reader

    HF 13.56 MHz, ISO 15693, 14443A(B) & 18000-3 Mode 1

  • UHF RFID Reader

    865 ~ 928MHz, EPCglobal Class 1 Gen 2/ISO 18000-6C; 16 ft (4.87m) Reading Distance with the Built-In ThingMagic Micro Module & Embedded Antenna; 30 ft (9.1m) Reading Distance with Trigger Grip

  • GNSS Module

    GPS Module

Accessories

    Digital Pen
    Digital Pen

    Dimensions: 9.7 mm x 140.7 mm; Weight: <25g; Battery: 1 AAAA.

    Desktop Charging Cradle
    Desktop Charging Cradle

    Charge one handheld tablet and one battery pack; ports for Power, USB, video-out, and Ethernet.

    4-Bay System Gang Charger
    4-Bay System Gang Charger

    Multi-bay charger, capable of charging up to 4 tablets simultaneously.

    6-Bay Battery Gang Charger
    6-Bay Battery Gang Charger

    Multi-bay charger, capable of charging up to 6 battery packs simultaneously.

    Trigger Grip for Barcode Scanner.png
    Trigger Grip for Barcode Scanner

    Supports to trigger the barcode scanner module.
    (Not compatible with long range 2D scanner SKU.)

    Trigger Grip for UHF RFID Reader and Barcode Scanner
    Trigger Grip for UHF RFID Reader

    Supports 30 feet UHF RFID Reader read distance.

    Charging Cradle for UHF RFID Reader Trigger Grip
    Charging Cradle for UHF RFID Reader Trigger Grip

    Supports to charge the trigger grip with DT362 tablet.

    Charging Cradle for UHF RFID Reader Trigger Grip
    Charging Cradle for Trigger Grip

    Supports to charge the trigger grip (without the antenna) with DT362 tablet.

    Trigger Grip for UHF RFID Reader and Barcode Scanner
    Trigger Grip for Long Range Barcode Scanner (With 6dB antenna)

    Supports to trigger the 2D barcode scanner module.

    Battery Packs
    Battery Packs

    3100mAh battery packs.

    AC/DC Power Adapter with Power Cord
    AC/DC Power Adapter with Power Cord

    Facilitates Tablet operation or battery recharge. USB Type-C connector.
